Motor Ex D: High-Efficiency Dust Explosion-Proof Solutions for Hazardous Industries

Shaanxi Qihe Xicheng Electromechanical Equipment Co., Ltd. delivers enterprise-grade motor ex d solutions through its YFBX4 series, engineered for combustible dust environments. Covering 0.55–315 kW power range across 380V–1140V voltage platforms, these motors achieve GB 18613-2020 Class 2 and IEC IE4 ultra-premium efficiency standards. With explosion-proof marks Ex tD A21/A22 IP65 T130℃ and maximum surface temperature strictly controlled below 130℃, YFBX4 motors provide reliable protection in Zone 20/21/22 hazardous locations. Backed by over 20 years of industry experience and partnerships with 30+ global motor manufacturers, we deliver certified solutions with CCC, CE, ISO9001, and CRCC compliance.

Motor Ex D Manufacturer and Supplier

As a specialized provider of power equipment solutions, we maintain strategic alliances with industry leaders including ABB, Siemens, Wolong, and XEMC. Our YFBX4 product series utilizes premium SKF, NSK, and FAG bearings replaceable per your specifications. Each unit undergoes rigorous factory acceptance testing through SAP-managed production systems, ensuring dimensional accuracy and thermal performance consistency across batch productions.

Pain Points vs. Solutions

Challenge: Dust accumulation causing motor overheating and ignition risk

Solution: Fully enclosed cast iron housing with multi-channel sealing blocks particle infiltration while maintaining ≤130℃ surface temperature

Challenge: Premature failure in high-vibration environments

Solution: Reinforced F-class insulation with IC411 self-cooling system extends service life 40% beyond standard models

Challenge: Compliance complexity across international markets

Solution: Pre-certified for GB/T 3836.31-2021, ATEX, and IECEx standards with complete technical documentation

Technical Advantages

The YFBX4 motor ex d features optimized fan cover gaps preventing heat blockage while dedicated dust-proof wiring chambers eliminate cable gland infiltration points. This design maintains 99.2% operational uptime in flour mills and chemical processing facilities.

​​​​​​​

Production Process

Our manufacturing workflow integrates precision machining with automated quality gates. Stator laminations undergo laser-cut tolerancing within ±0.02mm, while rotor balancing achieves ISO G2.5 vibration grades. Post-assembly testing includes hi-pot dielectric strength verification at 2.5kV and temperature-rise validation simulating 120% rated load conditions. Final inspection documents traceability codes linking raw material batches to finished units.

Industry Applications

· Grain Processing: Silo conveyor systems and hammer mills handling wheat/corn dust

· Pharmaceutical: Tablet coating machines and powder blending equipment

· Textile: Fiber carding units and spinning frame drives

· Metallurgy: Aluminum powder handling and metal grinding operations

· Building Materials: Cement bagging lines and gypsum processing plants

These motors operate reliably in -20℃ to +40℃ ambient temperatures with altitude compensation up to 1,000 meters.

Customization Capabilities

You gain access to tailored engineering services including shaft extension modifications, special flange dimensions per DIN/NEMA standards, and custom voltage/frequency configurations. Our R&D team adapts winding designs for variable frequency drive compatibility while maintaining explosion-proof integrity. Lead times range 15–25 days depending on specification complexity, supported by multimodal logistics including FOB/CIF/DDP Incoterms.

Reliability Testing & Certifications

Every motor completes:

· 72-hour burn-in testing under rated conditions

· IP ingress protection verification per IEC 60529

· Thermal imaging validation of hotspot distribution

· Vibration spectrum analysis across operational speed ranges

Current certifications include CCC, CE, ISO9001:2000, Railway CRCC, and UL/GOST for international markets. Documentation packages contain type test reports and explosion-proof certificate copies.

Why Choose XCMOTOR？

Original Components: Exclusively sourced from verified tier-1 suppliers

Fast Delivery: Consolidated shipping with real-time tracking

30-Day Returns: Hassle-free exchange policy

Dedicated Support: Technical assistance available weekends included

Our mature supply chain infrastructure ensures competitive pricing without compromising quality standards. You receive lifecycle support from selection consultation through warranty claims resolution.

FAQ

Q：What is YFBX4 dust explosion-proof motor, and what energy efficiency standard does it reach?

A：YFBX4 is a high-efficiency dust-protected three-phase aSynchronous Motor developed on the YBX4 platform. It meets GB 18613-2020 Class 2 energy efficiency and IEC IE4 standards, specifically designed for flammable dust hazardous areas.

Q：What are the standard dust explosion-proof marks of YFBX4?

A：Standard marks are Ex tb IIIB T130℃ Db and Ex tb IIIC T130℃ Db, compliant with GB/T 3836.31-2021 for Zone 20/21/22 applications involving grain, wood, plastic, metal, and chemical dust.

Q：What's the difference between YFBX4 and YBX4 motors?

A：YFBX4 limits surface temperature to prevent dust ignition with enhanced sealing, while YBX4 uses flameproof clearance for gas/vapor environments. YFBX4 exclusively serves combustible dust sites.

Q：What structural designs prevent dust explosion?

A：Thickened cast iron housing with multi-layer sealing, controlled surface temperature ≤130℃, fully sealed cable glands, and optimized fan geometry blocking dust accumulation.

Contact Us

Get precise motor ex d solutions matched to your operational requirements. Reach our engineering team at XCMOTORs@163.com">xcmotors@163.com  for specification sheets and quotations.
